Digital Electrical Multimeter

Digital Electrical Multimeter

Specifications:
– Measure AC/DC voltage, AC/DC current, resistance, frequency, continuity, diode and etc.
– Measuring Instrument with function of data hold, Maximum Value hold, backlight, function switching.
– DC voltage: 200mV – 1000V ± (0.5% + 2); Alternating voltage: 200mV – 700V ±(0.8% + 3); DC current: 2mA – 20A ± (1.2% + 2); Alternating current: 2mA -L8 20A ± (1.2% + 3)
– DC voltage: 200mV-1000V ± (0.5 %+2)
– AC voltage: 200mV-700V ± (0.8 % +3)
– DC current: 2mA-20A ± (1.2% +2)
– Alternating current: 2mA-20A ± (1.2% +3)
– Resistance: 200? – 200M? ± (0.8% + 2)
– Capacitance:2nF-200uF, ± (4.0% + 5)
– Max. Display:1999, 3 1/2
– Power: 9 v

• Crystal diode test: YES
• Diode testing: YES
• Conduction buzzer: YES
• Automatic shutdown: YES

Package includes:
1 x Digital Multimeter

Notices:
1.To avoid harms to you or damage to the meter from electric shock, please do not attempt to measure voltage higher than DC/AC 1000v.
2.Do not rely on non contact voltage detector to determine whether there is a voltage. The detection operation may be affected by socket design, insulation thickness and type of different factors.
3.Before measuring current, check the meter’s fuses and turn off power to the circuit before connecting the meter to the circuit.

What’s in the box
1x Digital Multimeter.
1x User manual.
1x 9V Battery.
